Drone jammer

←

→

Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System

Model：FH-BP-DJP

Customized Logo：OEM,ODM

MOQ：10

Specification

Parameters

Download

Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System


Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System Description FH-BP-DJP is a portable jamming detection system with comprehensive drone monitoring capabilities. It monitors the model and operating frequency of drones within the range through data mining and in-depth analysis of drone signals, and performs signal jamming on its own. Functional Deployment for Aerial Security Enforcement The Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System is engineered as a portable tactical tool for security professionals who require rapid deployment of aerial threat detection and mitigation capabilities. It facilitates detection, recognition, and suppression of unmanned aerial vehicles in diverse operational scenarios such as prisons, airports, and government complexes. Its backpack-mounted design supports mobile operations while enabling operators to maintain secure perimeters with real-time FPV detection and dynamic drone spoofing, optimizing aerial threat response without compromising agility or deployment speed. Advanced Technical Specifications Enabling Precision Control This intelligent system integrates multi-band drone detection and jamming technologies, covering GPS, BDS, GLONASS, and GALILEO frequencies with precise data mining to identify drone models and operating frequencies within a 1 to 3 km range. Modular controls allow for independent functioning of multiple jammer modules, maximizing signal disruption efficiency. The device achieves a jamming distance of up to 2 km utilizing noise technology under an IP65-rated rugged enclosure with an advanced cooling system, ensuring consistent performance in difficult environmental conditions and maintaining compliance with strict electromagnetic emission regulations. Operational Versatility Across Security and Industrial Domains The Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System supports diverse high-security applications including perimeter enforcement at detention facilities, no-fly zone protection at airports, and covert surveillance countermeasures in industrial complexes. Its GPS spoofing functions enable forced landings or directional displacement of target drones, thereby enhancing situational control. Integration into existing security frameworks is streamlined via network data interfaces, facilitating comprehensive aerial defense strategies across governmental, industrial, and event management sectors.

Product Advantages

Innovative Modular Design and Robust System Integration
This system’s modular architecture enables independent control of up to eight active jammer modules, facilitating configuration flexibility tailored to mission-specific requirements. The Backpack Drone Jammer FPV Detector And Drone Spoof System 1-3km Detection Intelligent System features a backpack format optimized for field operability, incorporating an IP65-rated enclosure and systematic smart cooling to sustain sustained operation in harsh environments. The ergonomic design concentrates on minimizing operator fatigue while maintaining access to precise control parameters and real-time data analytics for enhanced situational awareness in drone threat management.

High Performance Jamming and User-Centric Operational Efficiency
Equipped with sophisticated noise jamming technology, the system reliably disrupts drone communication and navigation signals across multiple satellite bands with a response time as low as two seconds. Its effective detection and spoofing capabilities furnish security teams with actionable intelligence and immediate control over UAV threats within a 1 to 3 km radius. The backpack configuration combined with network interface compatibility simplifies deployment logistics and facilitates seamless integration into comprehensive security protocols, offering operational scalability and optimized return on investment in aerial defense infrastructure.

GPS deception / GPS Spoof
The drone GPS spoofing system is a countermeasure device based on satellite navigation signal simulation and jamming technology.It can achieve accurate positioning misleading, hovering or forced landing control of drones. It can be used in sensitive area protection, counter-espionage reconnaissance, event security and other scenarios to ensure low-altitude full-area safety.

Product Information

2.4G/5.8G Wifi Signal Jammer Application:
Mainly applied to prisons, airports, scientific research centers, detention houses,
interrogation rooms, courthouses, labor camp, all kinds of important places, etc. that forbid aerial photography by use of UAV.

GPSL1/L2 Signal Jammer Features:
1. High integration & Stable operation, Noise technology.
2. Highly effective power & long jamming distance up to 2KM.
3. Separate control of each module, convenient operation.
4. High-quality tubular radiator, effective in radiating heat.
5. Import components, VSWR protection, Overheat protection
6. No interference to nearby frequency bands

Parameter

Channel	Working Frequency	Output Power(±1dBm)
CH1	400-450MHz	47 dBm(50W)
CH2	700-840MHz	47 dBm(50W)
CH3	840-960MHz	47 dBm(50W)
CH4	1100-1300MHz	47 dBm(50W)
CH5	1550-1610MHz	47 dBm(50W)
CH6	2400-2500MHz	47 dBm(50W)
CH7	5100-5300MHz	47 dBm(50W)
CH8	5700-5900MHz	47 dBm(50W)
Total output power	400W
Power consumption	900W
Power supply	AC90-260V, DC24-28V
Main engine weight	15KG
Size	*520400230mm*
jamming rang 1.5KM
Jammer Module Number	8
Cooling System	Systematic Smart Cooling System
Jamming Source	Noise Technology
Humidity	30%-95%
Running temperature	-20ºC to +70ºC

GPS deception / GPS Spoof
Product Specifications
1) Working frequency :
GPS/L 1(1575.42MHz ± 1.023MHz),
BDS/B 1(1561.098MHz±2.046MHz),
GLONASS/G 1(1602MHz±4MHz),
GALILEO/E 1(1575.42MHz ± 12.276MHz);
2) Navigation Spoofing Feature: Drone No-Fly Zone Projection (Forced Landing), Directional Displacement;
3) Defense distance: 1-5km ( PA RF power 25W);
4) Deception intervention time: 2s;
5) Effective deception angle: horizontal: 360 °, vertical: ±90 °;
6) Power supply method: 220V AC alternating current;
7) power consumption: ≤120W;
8) Data Interface: Network Port;
9) Protection level: IP65;
